QDMECH
HN-20260610-01
1.Durable Core Structure
Equipped with high-strength mold and dual pressure wheels. The key wearing parts feature excellent wear resistance, which extends the machine's service life and maintains long-term stable operation during continuous production
2.High Production Efficiency
Two models with different power and capacity for selection: QD-MTK250 (15kw, 150kg/h) and QD-MTK300 (22kw, 200kg/h). Both deliver large output and high working efficiency to improve production profits significantly
3.Reliable Electric Control System
Adopts genuine and standard electrical control components. The whole machine runs stably with low failure rate, ensuring safe and trouble-free daily operation for users
4.Complete Supporting Accessories
The machine is delivered with full set of standard accessories. Users can start production directly after simple installation, no extra parts purchasing is required, saving time and cost
5.Reasonable Overall Design
With compact overall size and solid body structure (600kg/800kg). It occupies small floor space, is easy to place and move, and adapts to various production environments such as home workshops and formal factories
| Machine Model | Motor Power | Dimensions (mm) | Weight (kg) | Output (kg/h) | Stage |
|---|---|---|---|---|---|
| Type 210 | 7.5KW | 870*500*920 (without hopper height) | 206 | 50-60 | 4-stage |
| Type 260 | 15KW | 1050*600*1340/1100 (without hopper height) | 350 | 80-120 | 4-stage |
| Type 300 | 18.5KW | 1200*600*1400/1070 (without hopper height) | 500 | 200-300 | 4-stage |
| Type 400 | 30KW | 1410*610*1560/1260 (without hopper height) | 870 | 400-500 | 4-stage |
| Type 500 | 55KW | 1700*800*1740/1500 (without hopper height) | 1400 | 600-800 | 4-stage |




A:It can process various biomass raw materials including wood sawdust, wood chips, bamboo scraps, straw, rice husk, peanut shells, charcoal powder and other agricultural/forestry residues.
A:The ideal moisture range is 10%-18%. Too wet or too dry material will affect pellet forming quality and output.
Q3:What size of pellets can the machine make?
A:Standard pellet diameter is 6-10mm. Customized orders take 7-15 working days. We support sea, air and express shipping to your port or address.
Q4:How to maintain the biomass pellet machine?
A:Regularly lubricate the bearings, check the wear of rollers and dies, clean the hopper and feeding system, and replace worn parts in time to ensure stable operation.Q5:Is installation guidance provided?
A:Yes, we provide detailed installation manuals, operation videos and online technical support to help you install and use the machine smoothly.Q6:What after-sales service is included?
A:We offer a 1-year warranty for the whole machine, lifetime technical support, and supply of spare parts at cost price.Q7:What is the lead time and delivery method?
A:Standard machines are in stock for fast delivery. Customized orders take 7-15 working days. We support sea, air and express shipping to your port or address.Q8:Can I get customized service for the machine?
A:Yes, we can customize the die size, voltage, power, and even the machine color and logo to meet your specific production needs.
